Sump Pits are integral components designed to collect larger volumes of water and debris before they enter the main drainage system. They help prevent blockage and facilitate easier maintenance, ensuring long-term efficiency of your drainage solution.
🗑 Collects debris to prevent downstream blockages
💦 Manages large volumes of water effectively
🧩 Modular design compatible with Click Drain® channels
🛠 Removable covers for easy cleaning and maintenance
⚙️ Connects seamlessly to outlet pipes and systems
🇦🇺 Constructed from high-quality 304/316 stainless steel
| Specification | Details |
|---|---|
| Dimensions | Matches channel widths; custom depths available |
| Material | 304/316 Stainless Steel |
| Access | Removable grates for maintenance |
| Connection | Click-fit to channels; standard pipe outlets |
| Load Class (with grating) | Up to Class D |
The frequency of cleaning depends on the environment and the amount of debris. Regular inspections are recommended to maintain optimal performance.
Yes, our sump pits are designed to connect seamlessly with standard plumbing systems. Custom connections can also be accommodated.
Standard sizes match our channel widths, but custom dimensions can be produced upon request to suit specific project requirements.
Choose Click Drain® End Cap
for your next install.
CLICK DRAIN® is self-supporting and does not require concrete to validate its CLASS load rating integrity.
